XAP125
Rated Productivity
120 t/h
Mixing Capacity
1,500 kg/batch
Fuel Consumption
6,5 kg/t
Operating Power
294 kW
Power Frequency
50 Hz
Control Room Noise
< 70dB
Basic specification
Rated productivity : 120 t/h
Nominal mixing capacity : 1500 kg/batch
Rated working condition:
Aggregate: ≤40mm 100%
Aggregate: ≤3mm 40%
Aggregate: ≤74um(ASTM200) 7%
Static dosing precision:
Bitumen ±0.2%
Filler ±0.2%
Minerals ±0.3%
Fuel consumption : ≤6.5 kg/t
Required operating power : About 294 kW (whichever is the actual configuration)
Maximum single unit power : 75 kW
Minimum installation area : 750(30m×25m) m2
Power supply:
Single voltage: 220V
Three phase: 380V
frequency: 50Hz
Environment protection standard:
Dust emission content : ≤20mg/Nm3(Rated working condition)
Smoke blackness : ≤Ringelmann 1st level
Ambient noise : ≤80dB
Control room noise : ≤70dB
